Find SABAF Replacement Burners: Compatibility Guide (LPG/NG)
The decision to replace worn-out gas burners with high-quality SABAF components is a smart move toward restoring or even improving your cooker’s efficiency. SABAF burners are renowned for their high thermal efficiency and durable brass construction.
However, finding the exact compatible model can be tricky. Unlike simple generic burners, SABAF produces a complex, modular range for dozens of appliance manufacturers worldwide. You can’t just buy a “large” or “small” one.
This detailed guide outlines the critical information you need to gather for a precise and successful replacement.
Step 1: Identify Your Hob’s DNA (The Non-Negotiable Details)
The most accurate way to find a compatible SABAF burner is to consult the appliance manufacturer first, but if that isn’t possible, these five details are crucial.
A. Appliance Brand and Model Number
This is your starting point. Manufacturers like Bosch, Elica, Prestige, and many others often specify exactly which SABAF series they use in a particular model (e.g., Faber Hob Model XYZ).
- Where to Find It: Look at the underside of the hob, the product manual, or the metal identification plate usually found near the gas inlet pipe.
B. The Gas Type (LPG vs. Natural Gas)
This is critical for safety and efficiency. Gas burners are factory-calibrated with specific gas jets (nozzles) for either LPG (Liquefied Petroleum Gas) or NG (Natural Gas). The jet orifice size differs significantly.
- Safety Note: Installing a burner set with the wrong jets can cause a dangerous flame, incomplete combustion, and a major drop in efficiency. Always specify your gas type.
C. Burner Type and Diameter (The Physical Fit)
The physical dimensions determine if the burner will sit correctly on your hob. You need to measure the size of the burner cups and the type of flame spreader.
| Burner Measurement | Required Detail | Why it Matters |
| Diameter (mm) | Measure the outer diameter of the burner cup or the burner cap. Standard SABAF diameters include 55 mm (Auxiliary), 75 mm (Semi-Rapid), 100 mm (Rapid), and 130 mm (Triple Ring). | Ensures the burner sits snugly into the hob surface cutout and under the pan support. |
| Ring/Flame Type | Single-Ring (Auxiliary), Double-Ring (Rapid), Triple-Ring (Wok/High Power), or Lotus/Tornado. | This dictates the power output (kW or BTU) and the specific flame structure of the replacement. |
| Material | Are you replacing brass with brass, or upgrading from a standard aluminum burner to a High-Efficiency brass unit? | Different materials interact differently with the cast iron pan supports. |
Export to Sheets
Step 2: Utilizing the SABAF Modular System (For Upgrades)
One of SABAF’s advantages is its modular design. For their popular Series 2 and Series 3 burners, the burner cup (the base piece) is often common across many versions.
This means that while your hob may have come with a standard Series 2 burner, you might be able to upgrade just the flame spreader and cap to a Series 2 HE (High Efficiency) Full Brass version, provided the cup dimensions match.
Can I Upgrade a Generic Burner to a SABAF High-Efficiency Burner?
A direct, universal upgrade is not guaranteed and is often risky due to the complexities of the gas flow system:
- Gas Jet/Injector: Generic burners might use a standard gas jet that is incompatible with the optimized air-gas mix ratio required by the SABAF High-Efficiency design.
- Burner Cup Fit: The base of a SABAF burner is highly specific. A generic hob’s mounting may not perfectly accommodate the precise air intake required by the SABAF cup, leading to an incorrect flame and potentially lower-than-expected efficiency.
Best Practice: The safest replacement is to seek out the exact SABAF series and model code specified by your hob manufacturer. If upgrading, consult a certified technician or a parts specialist to confirm the jet and cup compatibility.
Step 3: Where to Search for Your SABAF Replacement
Once you have gathered the required details, use these channels to secure your replacement:
- Original Appliance Manufacturer (OEM): Always the best source. Contact customer service for brands like Bosch, Elica, Faber, etc., and provide your hob model number. They will supply the precise, factory-matched SABAF part.
- Online Spare Parts Suppliers: Specialized online spare parts retailers often list components by SABAF’s original part codes (e.g., 3025327 for a specific burner cap). Search using your burner diameter (e.g., “SABAF burner cap 94 mm”) to find compatible listings.
- Local Appliance Repair Technicians: Certified gas technicians often have access to SABAF’s official parts catalogs and can confirm compatibility based on their knowledge of regional hob models.
Crucial Check: Whether buying a full burner set or just the cap, ensure the listing explicitly states compatibility with your desired gas type (LPG or NG).
SABAF Burner Replacement & Compatibility FAQs
These FAQs are designed to be thorough, directly address the challenges of finding the correct part, SABAF burner compatibility, gas jet size, LPG vs. Natural Gas burner, and replacing high-efficiency burners.
1. What exact information do I need to find a compatible SABAF burner replacement?
Finding the correct replacement requires four critical pieces of information:
- Hob Brand and Model Number: Found on the manual or the data plate under the hob.
- Burner Diameter (in mm): Measure the size of the burner cup and cap (e.g., 55 mm, 75 mm, 100 mm).
- Burner Type: Is it a standard single-ring, double-ring, or a high-power Triple Ring (Wok) burner?
- Gas Type: LPG (Liquefied Petroleum Gas) or NG (Natural Gas)? This dictates the required gas jet/nozzle size.
2. Can I simply replace my generic burner with a SABAF High-Efficiency burner?
It is generally not recommended without professional verification. While the visual size may be similar, SABAF’s High-Efficiency (HE) burners require a very specific air-to-gas mixture and a precise fit to function correctly.
If the burner cup, the gas jet (injector), or the mounting is not perfectly matched, the burner will not achieve its maximum efficiency and may produce a poor, yellow, or smoky flame. Always try to match the replacement to the hob’s original specifications.
3. Why is the Gas Type (LPG or NG) so crucial for burner replacement?
The gas type determines the required size of the gas jet (or injector).
- LPG is supplied at a higher pressure and requires smaller jet holes.
- Natural Gas (NG) is supplied at a lower pressure and requires larger jet holes.
Using the wrong jet can result in a dangerous, oversized flame (LPG jet with NG), or a weak, sputtering flame (NG jet with LPG). Compatibility must match the gas type you use.
4. How do I measure the burner to find the correct SABAF size?
Measure the outer diameter of the burner cap (the removable top piece) in millimeters (mm).
SABAF burners typically follow standard sizes related to their power output:
| Power (kW) | Common SABAF Size (mm) | Common Name |
| ∼1.0 kW | 55 mm | Auxiliary/Small |
| ∼1.75 kW | 75 mm | Semi-Rapid/Medium |
| ∼3.0 kW | 100 mm | Rapid/Large |
| ∼3.8 kW | 130 mm | Triple Ring/Wok |
Export to Sheets
5. Where can I find the specific SABAF part number for my hob?
The specific SABAF part number (a 7-digit code) is rarely found on the burner itself. Your best resources are:
- Your Hob’s Manual: Look under the “Technical Specifications” or “Spare Parts” section.
- Hob Manufacturer (OEM): Contact customer support for your hob brand (e.g., Elica, Faber) and provide your full hob model number. They are the most reliable source for the factory-matched replacement part code.
6. Why do different hob brands use the same SABAF burner?
SABAF is an original equipment manufacturer (OEM). They design and supply advanced components to many different appliance companies worldwide. A specific burner model (like the Series 2 HE) can be used by brands across the globe, which is why burner details and sizes are standardized, making it easier for specialists to find compatible SABAF replacement parts.
